Easy Operation Servo Motor Cnc Carving Machine For Acrylic
MINTECH T-6 is a popular, heavy-duty cnc routers engineered to
provide the highest combination of quality and precision, which
incorporates the reliability, robustness and cutting edge
technology and has always been one of the hot sale of MinTech
products.It offers the perfect platform for high-speed,
vibration-free processing of even the toughest materials aiming at
signmaking, non ferrous metal fabrication , plastic &acrylic
fabrication ,3D carving that require extremely high tolerances.
1. Gantry
Engineered for Performance
2. Gantry Supports
High Strength, Minimal Vibration
3. Base Frame
Solid, Heavy-Duty Construction
4. Working Surfaces
Versatile, Effective, Multi-functional
5. Z Axis Assembly
Precise & Robust , Ball Screw Assembly
6. Control System
Easy-To-Use WEIHONG NK280 .
7. Helical Rack & Linear Bearings Fluid & Accurate ,Helical rack
provides superiorly smooth motion along X & Y axis 8.Digital Servo
Drive System
Powerful & Reliable
9. Router Spindles
Multiple Options for Increased Productivity
10. Drive Assembly
High Acceleration, Excellent Cut Quality
11. Automatic Tool Changer(ATC)
Optimized for Faster Throughput
| Parameter | Remarks |
| Working area | X axial processing scope | 1300mm | |
| Y axial processing scope | 2500mm | |
| Z axial processing scope | 60mm | |
| Machine parameter index | X,Y,Z axial motion positioning accuracy | 0.05mm | |
| X,Y,Z repeated positioning accuracy | 0.05mm | |
| Maximum displacement speed | 30m/minute | |
| Maximum processing speed | 20m/minute | |
| total weight of machine tools | About 2000KG | |
| machine tool operating voltage | AC380V/OR 220V/50-60HZ/3PH | |
| Working table | phenolic panel table | vacuum adsorption table | |
| worktable load | 380KG | |
| Software | Wei Hong professional numerical control system | NK 260 | |
| Tool changer- ATC | row | 5pcs in one row | option |
| Drive power( SERVO MOTOR ) | X axial drive motor | Delta | |
| Y axial drive motor | Delta | |
| Z axial drive motor | Delta | |
| Electric spindle(frequency conversion) | spindle | Air cooling | |
| spindle speed | 24000RPM | |
| spindle power | 9KW | |
| Guide rail | X axle guide rail | square guide rail (25mm) | |
| Y axle guide rail | square guide rail (20mm) | |
| Z axle guide rail | square guide rail (20mm) | |
| Drive | X shaft drive | bevel teeth | |
| Y shaft drive | bevel teeth | |
| Z shaft drive | ball screw |
Professional Team
24 hours * 7 days online service,answer all your questions.
Installation Instructions
Provide video tutorials or send our engineers on-site for
installation
1 Year Warranty
one year machine warranty , Provide lifetime maintenance service
FAQ:
Q: I knew nothing about this machine, what kindof machine i should
choose?
A: Just tell us what you want to do byusing CNC machine, then let
us give you perfectsolutions and suggestions.
Q: What technical services can you provide?
A: We will send video and English manual with the machine. And
24-hour professional technicians online training and problem
solving. It provide detailed installation courses.
Q: If some problems happen to this machineduring warranty period,
what should I do?
A: We will supply free parts during machine warranty periodif
machine have some problems. While we also supplyfree life long
after-sales service. So any doubts, just let usknow, we will give
you solutions.
