1325 atc woodworking machinery cnc router machine (T6)

Mintech T6 CNC router machine is the producing and processing equipment specially designed for advertising signs, exhibition display, LED light guide plate, LED sign letter, acrylic products, insulation materials, aluminum, copper, such as sheet metal industry, by virtue of the entire steel frame structure, high precision imported skew rack and import guide rail coordinates the transmission table is fixed, high standard design, won the award in the manufacturing industry in the "most popular", also won the majority of users praise!

T6 standard features:

1. WEIHONG friendly user operating system.
2. Imported linear guide rail.
3. Imported high precision transmission cable rack, gear, stable running fast.
4.25000-30000mm/ minutes idle fast movement.
5. Automatic tool calibration system.
6. USB and network file transfer function.
7. Table is fixed, Longmen frame moving.
8. Power requirements: 3P 380V/50HZ.

No.	Content		T6	Remarks
1	Travel	X-axis working area	1270
		Y-axis working area	2540
		Z-axis working area	150
		All Machine size (mm)	3280x2120x2000mm
2	Parameter	XYZ axis motion positioning accuracy	+/-0.05
		XYZ axis Repeat positioning accuracy	+/-0.05
		Idle speed	30000mm/min
		The maximum processing speed	25000mm/min
		Working voltage	AC380V/50HZ 3PH
3	Spindle	Main properties	Air cooling	Italy(Automatic tool change)
		Spindle speed	24000RPM
		Spindle power	9KW
		Taper of spindle	ISO30ER32
		Spindle balance level	G2.5
4	Rail	Linear guide rail	PMI	Taiwan
5	Rack	Oblique rack	WMH	Germany
6	Bearing Seat	The bearing seat	Imported	Taiwan

T6 machines technology parameter:

1. Type: Mintech T6 router machine
2. Working area: 1270x 2540mm;
3. The Z axis beam to the table distance: 150mm;
4. Z axis travel: 200mm;
5. Repeat positioning: +/-0.05mm;
6. Cutting speed: 25000mm/min;
7. Moving speed: 30000mm/min;

8. Drive system: X, Y, Z adopts brushless servo drive, high precision skew rack and import guide rail coordinates;
9. The clamping way: Four vacuum adsorption partition table

Guarantee & After-sale service:

1. One year warranty under normal use and we supply lifelong maintenance.
2. 24 hours technical support by Phone, Email, Skype, Msn, or romote.
3. Free training to make sure you master the operation of machine .

OEM Service Available:

1. Usually, we will manufacturer the machine as our regular design.
2. working size could be custmer-oriented designing.
3. Special configuration and machine color could be customer-oriented designing.

FAQ:

Q:I knew nothing about this machine, what kindof machine i should choose?
A:Just tell us what you want to do byusing CNC machine, then let us give you perfectsolutions and suggestions.

Q:What technical services can you provide?
A:We will send video and English manual with the machine. And 24-hour professional technicians online training and problem
solving. It provide detailed installation courses.

Q:If some problems happen to this machineduring warranty period, what should I do?
A:We will supply free parts during machine warranty periodif machine have some problems. While we also supplyfree life long
after-sales service. So any doubts, just let usknow, we will give you solutions.​
